Here you will find PDFs of our CAD Details that illustrate how our system installs on different surfaces and in and around various architectural features. These are perfect for use in your project plans and specs.
Videos Gallery  01/05/2024

4 days 10 hours 40 minutes

5
TYPICAL WALL LAYOUT WITH CROWN - FS005-020

CAD Detail of Slim-Line® FS005 1/4" Square Front-Load Profile system being installed on drywall above a baseboard and below a crown molding with an intermediate joint joining two panels.

Slim-Line® 1/4 inch
View all
TYPICAL WALL LAYOUT WITH CROWN - FS005-020
Preview

CAD Detail of Slim-Line® FS005 1/4" Square Front-Load Profile system being installed on drywall above a baseboard and below a crown molding with an intermediate joint joining two panels.

OUTSIDE CORNER NO TRACK - FS005-021
Preview

CAD Detail of Slim-Line® FS005 1/4" Square Front-Load Profile system being installed on drywall to cover an outside corner where two walls meet. This method uses wood or MDF blocking with no track.

TYPICAL WALL LAYOUT WITH INTERMEDIATE - FS005-019
Preview

CAD Detail of Slim-Line® FS005 1/4" Square Front-Load Profile system being installed on drywall and above a baseboard with a horizontal intermediate joint joining two panels.

DOORS WINDOWS - FS005-004
Preview

CAD Detail of Slim-Line® FS005 1/4" Square Front-Load Profile system being installed on drywall next to door and window trim.

Classic-Line® 1/2 inch
View all
HALF INCH SQUARE OUTSIDE CORNER NO TRACK - FS100-021
Preview

CAD Detail of Square Outside Corner using the Classic-Line® FS100 1/2" Square Front-Load Profile system.

BASE COUNTERTOPS - FS100-001
Preview

CAD Detail of Classic-Line® FS100 1/2" Square Front-Load Profile system being installed on drywall above a baseboard or countertop backsplash.

INSIDE CORNER - FS100-005
Preview

CAD Detail of Classic-Line® FS100 1/2" Square Front-Load Profile system being installed on drywall at an inside corner where one wall meets another.

INTERMEDIATE-JOINT - FS100-006
Preview

CAD Detail of Classic-Line® FS100 1/2" Square Front-Load Profile system being installed on drywall to create an intermediate or seam joint between two adjacent panels.

Full-Line® 1 inch
View all
TYPICAL BASEMENT LAYOUT WITH CHAIR RAIL - FS100-011
Preview

Typical basement layout CAD Detail of Classic-Line® FS100 1/2" Square Front-Load Profile system being installed on drywall below a ceiling, above and below a chair rail and above a baseboard.

TYPICAL 1 INCH BASEMENT LAYOUT WITH CHAIR RAIL - FS100-008
Preview

CAD Detail of Classic-Line® FS100 1/2" Square Front-Load Profile system being installed on 1" shim material below a ceiling, above and below a chair rail and above a baseboard.

TYPICAL 1 INCH BASEMENT LAYOUT WITH CROWN - FS100-009
Preview

CAD Detail of Classic-Line® FS100 1/2" Square Front-Load Profile system being installed on 1" shim material below a crown molding and above a baseboard.

TYPICAL 1 INCH BASEMENT LAYOUT WITH INTERMEDIATE - FS100-010
Preview

CAD Detail of Classic-Line® FS100 1/2" Square Front-Load Profile system being installed on 1" shim material below a ceiling, above and above a baseboard with an intermediate joint.

Max-Line® 2 inch+
View all
TYPICAL WALL 2 INCH LAYOUT WITH INTERMEDIATE - FS150HF-011
Preview

CAD Detail of Full-Line® FS150HF 1" Square Front-Load Profile system.

INTERMEDIATE JOINT FS230
Preview

CAD Detail of Classic-Line® FS230 1/2" Beveled Intermediate Profile system.

TYPICAL WALL LAYOUT W CHAIR RAIL - FS150LF-013
Preview

CAD Detail of Full-Line® FS150LF 1" Square Front-Load Profile system.

Deluxe-Line® 2 Inch
View all
OUTSIDE CORNER - FS300
Preview

CAD Detail of Deluxe-Line® FS300 2" Square Front-Load Profile system.

INTERMEDIATE JOINT - FS300
Preview

CAD Detail of Deluxe-Line® FS300 2" Square Front-Load Profile system.

BASEBOARD - FS300
Preview

CAD Detail of Deluxe-Line® FS300 2" Square Front-Load Profile system.

CEILINGS / SOFFITS - FS300
Preview

CAD Detail of Deluxe-Line® FS300 2" Square Front-Load Profile system.
